Honing and Superfinishing Applications

Honed surfaces have excellent tribological properties – high bearing area ratio, low surface roughness and defined cross hatch pattern for lubricant retention. Tight bore size and cylindricity control coupled with enhanced tribological characteristics extend the life of bearings.

Nagel has successfully installed thousands of honing systems all across the globe in Automotive, Aerospace, Hydraulic, Lawn & Garden, Oil & Natural Gas, Appliance, Medical and other industries.
Engine: Cylinder Bore, Cylinder Liner, Crank Bore, Connecting Rod, Diesel fuel injection components, Crankshaft Pulley, Rocker Arm, Turbo Charger Valve, Roller Lifter, VVT components.
Transmission & Chassis: Pinion Gear, Differential Gears, ABS Control Valve, Steering Housing, Brake Drum, Brake Cylinder, Brake Valve, and Stator. Hydraulics: Axial Flow Pumps, Rotary Oil Pumps, Gear Pump, Radial Piston Housing and Valves.

Superfinishing Machine SE01-50N-T

Superfinished surfaces have excellent tribological properties – high bearing area ratio, low surface roughness and defined cross hatch pattern for lubricant retention for bearings and no lead coarser surface finish for seals. Removal of unstable amorphous layer, tight size control coupled with enhanced tribological characteristics significantly extends the life of bearing and seal surfaces.

Nagel has successfully installed thousands of superfinishing systems all across the globe in Automotive, Aerospace, Hydraulic, Lawn & Garden, Oil & Natural Gas, Appliance, Medical and other industries.

Engine: Crankshaft, Cam Shaft, Piston Pin, Balance Shaft, Fuel Injection Components, Rollers for Rockers, and Rocker Shafts.
Transmission & Chassis: Gear Faces, Transmission Shafts, Steering Rack, Planet Gear, Sun Gear, Shock Absorber Rod, and Brake Disk.
Hydraulics: Gear Pump Shaft, Gear Pump Thrust Face, Body and Spherical Head of Hydraulic Piston.
Bearings: Needle Bearings, Inner Race, Outer Race, and Cylindrical Roller Bearings.
Medical: Orthopedic and Spine Implants.

View and Download Application Examples in PDF Form
